Moving coil ammeters (dc)

BM45 10A

BM45 10A, Ammeter

Code: M11453.CONSULTAR DISPONIBILIDAD

  • Scale: 90º , P1
  • Accuracy: 1,5
  • Measurement Range (A): 10
  • Device: BM45

INFORMATION

Description

  • No need for auxiliary power supply
  • Precision class 1.5
  • Measurement in DC 25 uA ... 60 A, or ... 60 mV
  • Exchangeable scales

Applications

In direct current applications, to control the state of the current quickly and visually.

SPECIFICATIONS

Mechanical characteristics
Size (mm) width x height x depth
85 x 52 x 65 (mm)
Weight (kg)
0,15
Environmental characteristics
Protection class
Panel: IP 52 (Front), IP 00 (Terminals)
Storage temperature
-25…+40 °C
Working temperature
+10 … +30 °C
Standards
Certifications
CE, UL
Electrical safety, Maximum height (m)
2000
Standards
BS 89, UNE-EN 60051, IEC 144, UL94, DIN 43780, IEC 51, UNE 21318
Current measurement circuit
Consumption
60 mV
Allowable overload
1,2 In permanent / 5 In during 30s / 10 In during 5s / 40 In during 1s
Electrical characteristics
Insulation voltage, circuit
2 kV a 50Hz < 1 min entre mecanismo y caja
Measurement accuracy
Accuracy
1,5 % FE
