Line. Energy Efficiency is as easy as that!

Integral Energy Management System

It has never been easier

Total flexibility for any installation

The Line devices which are part of the integral Energy Management System (EMSi) offers multiple combinations, allowing you to create a solution custom-made for each installation.

Easy installation

The modular design of the system allows any associated Line device to be installed quickly, securely and automatically thanks to its integrated Bus-Line communications.

Discover the new EMSi system

Control and manage your installation: EMSi

The devices in the Line system paved the way for the EMSi concept, which combines the management of different types of energy consumption and the management of multiple control and maintenance systems (lighting, HVAC, etc.) into a single solution.



Management of all your consumption

The EMSi system records all the information on your installation's energy consumption, which it can monitor in real time, display it on graphs, compare data from different periods or display it in data tables so it can be exported outside the application.

The data acquisition is very simple; using the line-EDS device, you can add any meter with Modbus communications to the EMSi system; the Line-M devices with digital inputs let you record consumption using any meter with a pulse output. The electricity consumption is recorded using the Line-CVM-D32 analyzer.

The EMSi software integrated into line-EDS lets you create SCADA displays to show, in real time, where, how, when and how much energy your installation is consuming. This information lets you save on costs and manage the installation globally based on the ISO 50001 standard.

Find out how and where you consume energy.

Monitor every circuit in your installation

Monitor any type of installation

Install Line-EDS and integrate any Modbus RTU or Modbus TCP device that is present in your installation (temperature, humidity, pressure, level or other kind of probe).

Create SCADA screens to control all your automation systems from a single device (Line-EDS). You can use any web browser or PowerStudio Server to control and display the status of your installation in real time, change any setpoint and receive alarms to improve the management of all your control systems.

Easily and dynamically display any regulation system required, such as:

Lighting control

Configure setpoints to automatically turn lights on and off, on a set schedule or by using the astronomical clock feature. It also offers the option to control lighting systems by creating a work schedule, with or without inputs from motion sensors.

Example of lighting control

HVAC control

Take external temperature readings, compare them with the setpoint and turn on the HVAC system to drive and monitor the hot water loop. Monitor the condition of the compressors to display the percent load on each and verify they are working correctly.

Example of HVAC control

Temperature control

Check the status of each HVAC unit and adjust the hot/cold setpoints as needed. Create calendars or schedules to program automatic on/ off switching times. Each device can be set based on the schedule or workday, with the option to incorporate motion sensors into the control system.

Example of temperature control

Note: The sample screens shown are not set up by default on Line-EDS devices. Each user will be able to generate their own screens based on their needs.

Maintenance of any installation

Program any type of alarm to monitor the installation depending on the variables of the connected devices. If any parameter is outside its programmed values, the system will adjust the installation and/or send an e-mail instantly.

It combines every aspect of energy control into a single tool, providing invoice simulations based on the energy consumption of any meter.

Know what the utility will bill in advance and schedule an automatic notification to compare and improve the efficiency of your consumption.

Create Energy Performance Indicators (EnPI) to chack if energy improvement actions are working correctly. Create your own KPI, depending on your installation and processes.





Typical performance indicators:

Two models, four types of management.

With the Line system devices, you decide how to manage any installation. Manage them using IoT cloud platforms or with our integral Energy Management System, working locally or remotely.

System features:

• Compatible with the major IoT platforms for Big Data analysis.
• Distributed system, allowing data from multiple installations to be centralized in the same system.
• Connect from anywhere with internet access.
• Does not require installing and maintaining a local server.
• No programming specialists required.

Examples of IoT platforms

Azure platform

AWS platform



EMSi (Integral Energy Management System)

Manage consumption + Installation control + Maintenance

System features:

• Line-EDS-PS incorporates EMSi software for the integral management of installations.
• Access EMSi from any web browser, whether in local or remote mode.
• Does not require installing and maintaining a local server.
• Generic Modbus driver to add any device on the market.
• Internal memory for data analysis and traceability using graphs and tables.
• Energy consumption management.
• Automatic control of installations.
• Alarms and billing simulation for proper maintenance.

Accessible via Webserver or PowerStudio

System features:

• Manage your installation from your own server (PowerStudio Server).
• Add as many devices as you want with PowerStudio Server.
• Access EMSi from any web browser, whether in local or remote mode.
• Redundant database through the installation of Line-EDS-PS devices.
• No limit on memory for data analysis and traceability using graphs and tables.

Features of the monitoring and control system using Line-EDS-PS



System features:

• Create your Line solution using as many devices as you need, and expand it at any time.
• Manage your installation from your own server (PowerStudio software).
• Access EMSi from any web browser, whether in local or remote mode.
• Add as many devices to your communications network as you want with PowerStudio.
• No limit on memory for data analysis and traceability using graphs and tables.



Discover the 4 types of management in this webinar

---

Line system devices

Complete modular system for energy management

Line-M-3G Modem for 3G communications	Line-EDS Datalogger with integrated Webserver – Line-EDS-Cloud Line-EDS-PS Line-EDS-PSS Line-EDS-PSS-PRO	Line-CVM Power analyzer – Line-CVM-D32	Line-M-4IO Input/output modules – Line-M-4IO-T Line-M-4IO-R Line-M-4IO-RV Line-M-4IO-A	Line-M-20I Module with 20 digital inputs – Line-M-20I	Line-TCPRS1 RS-485 to Ethernet/Wi-Fi converter	Line-M-EXT-PS Power supply



Discover more about the first and unique EMSi of the market

LINE. integral Energy Management System, is that easy as that!
