Avoid inductive and capacitive reactive penalties by installing the new SVGm

Nowadays, utilities are penalizing those installations with inductive reactive energy consumption. The trend, in most countries, is to demand cosines of phi close to 1, even penalizing those installations that consume capacitive reactive energy.
For this reason we present our Static Var Generator SVGm. Solution with reduced dimensions to prevent your installation from exceeding the consumption limits of both inductive and capacitive reactive energy.

Discover the key aspects to avoid reactive penalties with the greatest efficiency.

SVGm compensates the reactive energy in your installation, helping you to save in two ways.

Ø penalties in any type of installation

Eliminates the monthly penalty fee applied by the utility company, both for reactive inductive and capacitive energy.

Optimize your installation

Reactive energy compensation reduces the circulation of current through the installation's cables, preventing overheating and tripping of the protections. It also optimizes the performance of your installation's power transformer.

Discover all the benefits of installing the SVGm

Avoid any kind of penalty for reactive energy

Accurate

It allows a target cos ϕ to be set, ranging from 0.7 inductive to 0.7 capacitive. The device compensates the exact amount of reactive current to achieve the set target value.

It has individual phase compensation to adjust the total cos ϕ, avoiding any kind of reactive consumption.

Adaptable to any type of installation, no matter how fast the loads fluctuate

Fast

SVGm has the most advanced technology in switching elements. With a response time of less than 20ms.

The device is prepared to instantly compensate networks with high consumption fluctuations.

It is not affected by harmonics present in your installation.

Immune

SVGm uses power electronics to compensate reactive energy. As it has no passive elements, the device can be installed in any type of network with a high presence of harmonic currents without affecting its performance.

Minimal maintenance required

Efficient

The operation of SVGm does not require mechanical components for its operation, avoiding the need for maintenance and replacement of its components.

Unlike conventional compensation devices via contactor, no transients are produced because the technology is not based on the connection of capacitors.

Easy commissioning

Easy start-up

In just 3 steps the device starts to compensate. Initial set-up can be performed either on-site, via the touch screen, or remotely via communications.

Display of compensation status and electrical parameter readings on screen, with colour diagrams and graphs for simplified interpretation and instant recognition of the device's operating status.

Remote management from anywhere

Communicable

Ethernet connectivity for complete management of the device, either locally or remotely, for access to the logs stored in the memory or for configuration and commissioning. Access to the web server is possible from any browser, either via mobile or PC.

Up to 7 years of log data stored in its 2 Gb memory, ready for access via integrated web server.

Everything you need for the most accurate compensation



Available in three formats

Wall mounted	Cabinet IP20/41	Cabinet IP54
30 kvar 60 kvar 100 kvar	100 kvar 200 kvar 300 kvar 400 kvar	100 kvar 200 kvar 300 kvar 400 kvar



Where to install the SVGm Static Var Compensator?

Thanks to its features, SVGm is a versatile device that can be installed in a multitude of applications, both at industrial level and in the service or infrastructure sector.

Industrial ovens, welding devices, electric motors with frequency inverters, telecommunications infrastructures, hospitals or airports (lifts and stairways), data centres, paper industry, electric generators ...
